Contaminated Runways 19
Performance Considerations
Part B of the Ops Manual will contain type specific information on procedures associated with take-off and landing on contaminated runways, together with performance data and any wind limitations. (Crosswind, tail wind and possibly headwind gust limits).
SNOWTAMs
SNOWTAMs are issued by aerodromes where contamination is a common occurrence. ATPL students are to be familiar with item (F), type of contaminant, item (G), depth of contaminant over each third of the runway in mm, and item (H), braking action on each third of the runway, stated as a 2 figure number to indicate measured coefficient, or a one figure number to indicate braking action. The validity of a SNOWTAM is up to 24 hours. The codes for types of contaminant are:
NIL CLEAR AND DRY
1DAMP
2WET or water patches
3RIME OR FROST COVERED (depth normally < 1 mm)
4DRY SNOW
5WET SNOW
6SLUSH
7ICE
8COMPACTED OR ROLLED SNOW
9FROZEN RUTS OR RIDGES
The following are examples of SNOWTAMS;
Note: Validity of a SNOWTAM is 24 hours.
SWED0072 EDDM 12110810 |
|
|
|
|
(SNOWTAM0072) |
|
|
|
|
(A) EDDM |
(B) 12110810 |
(C) 08L |
( F) 6/6/6 (G) 01/01/01H |
(H) 35/26/26 |
(N) 2,6 (R) 2,6 (T) RWY 08l PLANNED TO BE CLOSED DUE TO SLUSH REMOVAL
This decode is as follows:
AMunich
B11 Dec 0810Z
CRwy 08L
FOver the whole of the runway there is slush reported
GThe mean depth of the slush is 1 mm over the entire length
HThe friction measurements are:
|
(1st third) |
0.35 |
(medium) |
|
(2nd third) |
0.26 |
(medium/poor) |
|
(3rd third) |
0.26 |
(medium/poor) |
N |
Taxiway is contaminated with wet slush |
||
R |
Apron is contaminated with wet slush |
||
T |
Remarks (self-explanatory) |
Contaminated Runways 19
235
19 Contaminated Runways
(A) EDDF |
(B) 12111215 |
(C) 07L (F) 1/1/1 (G) XX/XX/XX |
(H) 5/5/5 |
(N) 2/5/6 |
(R) 2/5/6 |
(T) TWYS AND APRON SLIPPERY |
|
AFrankfurt
B11 December 1215Z
CRwy 07L
FRunway is damp over the entire length
GMean depth of the contaminant is not measurable
HBraking action over the entire length of the runway is good
N Taxiway is contaminated with water patches, wet snow and slush
R Apron is contaminated with water patches, wet snow and slush
T Remarks - Taxiways and apron are slippery
The decode of the nature of the contaminant is on the SNOWTAM form.
Note: Item D is the cleared runway length in metres. If less than published see item T. Item T. Describe in plain language any uncleared length in metres.
Runways Contaminated 19
236
Questions 19
Questions
1.If 30% of the surface area of a runway is covered by surface water more than 3 mm deep, by slush, by loose snow or compacted snow which resists further compression, or ice (including wet ice), the runway is classified as:
a.wet
b.contaminated
c.unusable
d.useable with care
2.If the surface of a runway is not dry, but the moisture on it does not give a shiny appearance, the runway is:
a.wet
b.wet but not contaminated
c.dry
d.damp
3.If a runway is covered with water which is less than 3 mm deep, or where the surface appears reflective but without standing water patches, it is said to be:
a.wet
b.wet but not contaminated
c.dry
d.damp
4.A dry runway is one which:
a.can be wet if it has sufficient camber to allow the water to drain quickly off the surface therefore maintaining an ‘effective dry’ braking action
b.is wet but not to a depth of water greater than 3 mm
c.is not contaminated
d.can be wet if it has specially prepared grooved or porous surfaces, which
maintain ‘effectively dry’ braking action
5.If a runway is contaminated with dry snow, the depth that will preclude operations is:
a.60 mm
b.15 mm
c.10 mm
d.3 mm
6.If a runway is contaminated with wet snow, slush or water, the depth that will preclude operations is:
a.60 mm
b.15 mm
c.10 mm
d.3 mm
Questions 19
237
19 Questions
Questions 19
7.The effect whereby a tyre is lifted from the runway due to aeroplane speed along the runway is known as:
a.surface water effect
b.hydroplaning
c.aqua-skimming
d.surface tension
8.For any given contaminant (by specific gravity), the aquaplaning speed is given by:
a.nine times the square of the tyre pressure (lb/sq in)
b.the tyre pressure (bars) divided by nine
c.nine times the square root of the tyre pressure (lb/sq in)
d.the square root of the tyre pressure (bars) multiplied by nine
9.One bar (barometric pressure unit) is equal to:
a.14.5 psi
b.28.82 in Hg
c.29.92 lb/sq in
d.1013.25 hPa m-2
10.Braking action on contaminated runways is given by:
a.a simple code (1 – 5) or a description (excellent - bad)
b.a simple code (0.25 – 0.4) or a description (good – bad)
c.a simple code (1 – 5), a description (good – poor) or the measured coefficient of braking effect (< 0.25 - > 0.40)
d.the coefficient of braking action related to a simple code where 1 is poor and 5 is good, supplemented by a description of the braking effect and an aquaplaning warning
11.Apart from aquaplaning and reduced braking efficiency, what other hazards are associated with heavy rain contamination of runways?
a.Wet aeroplanes do not perform as well as dry ones
b.The efficiency of jet engines is reduced by the ingress of water diluting the fuel
c.The refraction of light from landing lights causes visual impairment
d.Water ingress into engines can cause flame-out
12.In a SNOWTAM information is given concerning friction measurements (braking coefficient × 100) in which field of the message?
a.F
b.G
c.H
d.N
238
Questions 19
Questions 19
239
