- •Preface
- •Imaging Microscopic Features
- •Measuring the Crystal Structure
- •References
- •Contents
- •1.4 Simulating the Effects of Elastic Scattering: Monte Carlo Calculations
- •What Are the Main Features of the Beam Electron Interaction Volume?
- •How Does the Interaction Volume Change with Composition?
- •How Does the Interaction Volume Change with Incident Beam Energy?
- •How Does the Interaction Volume Change with Specimen Tilt?
- •1.5 A Range Equation To Estimate the Size of the Interaction Volume
- •References
- •2: Backscattered Electrons
- •2.1 Origin
- •2.2.1 BSE Response to Specimen Composition (η vs. Atomic Number, Z)
- •SEM Image Contrast with BSE: “Atomic Number Contrast”
- •SEM Image Contrast: “BSE Topographic Contrast—Number Effects”
- •2.2.3 Angular Distribution of Backscattering
- •Beam Incident at an Acute Angle to the Specimen Surface (Specimen Tilt > 0°)
- •SEM Image Contrast: “BSE Topographic Contrast—Trajectory Effects”
- •2.2.4 Spatial Distribution of Backscattering
- •Depth Distribution of Backscattering
- •Radial Distribution of Backscattered Electrons
- •2.3 Summary
- •References
- •3: Secondary Electrons
- •3.1 Origin
- •3.2 Energy Distribution
- •3.3 Escape Depth of Secondary Electrons
- •3.8 Spatial Characteristics of Secondary Electrons
- •References
- •4: X-Rays
- •4.1 Overview
- •4.2 Characteristic X-Rays
- •4.2.1 Origin
- •4.2.2 Fluorescence Yield
- •4.2.3 X-Ray Families
- •4.2.4 X-Ray Nomenclature
- •4.2.6 Characteristic X-Ray Intensity
- •Isolated Atoms
- •X-Ray Production in Thin Foils
- •X-Ray Intensity Emitted from Thick, Solid Specimens
- •4.3 X-Ray Continuum (bremsstrahlung)
- •4.3.1 X-Ray Continuum Intensity
- •4.3.3 Range of X-ray Production
- •4.4 X-Ray Absorption
- •4.5 X-Ray Fluorescence
- •References
- •5.1 Electron Beam Parameters
- •5.2 Electron Optical Parameters
- •5.2.1 Beam Energy
- •Landing Energy
- •5.2.2 Beam Diameter
- •5.2.3 Beam Current
- •5.2.4 Beam Current Density
- •5.2.5 Beam Convergence Angle, α
- •5.2.6 Beam Solid Angle
- •5.2.7 Electron Optical Brightness, β
- •Brightness Equation
- •5.2.8 Focus
- •Astigmatism
- •5.3 SEM Imaging Modes
- •5.3.1 High Depth-of-Field Mode
- •5.3.2 High-Current Mode
- •5.3.3 Resolution Mode
- •5.3.4 Low-Voltage Mode
- •5.4 Electron Detectors
- •5.4.1 Important Properties of BSE and SE for Detector Design and Operation
- •Abundance
- •Angular Distribution
- •Kinetic Energy Response
- •5.4.2 Detector Characteristics
- •Angular Measures for Electron Detectors
- •Elevation (Take-Off) Angle, ψ, and Azimuthal Angle, ζ
- •Solid Angle, Ω
- •Energy Response
- •Bandwidth
- •5.4.3 Common Types of Electron Detectors
- •Backscattered Electrons
- •Passive Detectors
- •Scintillation Detectors
- •Semiconductor BSE Detectors
- •5.4.4 Secondary Electron Detectors
- •Everhart–Thornley Detector
- •Through-the-Lens (TTL) Electron Detectors
- •TTL SE Detector
- •TTL BSE Detector
- •Measuring the DQE: BSE Semiconductor Detector
- •References
- •6: Image Formation
- •6.1 Image Construction by Scanning Action
- •6.2 Magnification
- •6.3 Making Dimensional Measurements With the SEM: How Big Is That Feature?
- •Using a Calibrated Structure in ImageJ-Fiji
- •6.4 Image Defects
- •6.4.1 Projection Distortion (Foreshortening)
- •6.4.2 Image Defocusing (Blurring)
- •6.5 Making Measurements on Surfaces With Arbitrary Topography: Stereomicroscopy
- •6.5.1 Qualitative Stereomicroscopy
- •Fixed beam, Specimen Position Altered
- •Fixed Specimen, Beam Incidence Angle Changed
- •6.5.2 Quantitative Stereomicroscopy
- •Measuring a Simple Vertical Displacement
- •References
- •7: SEM Image Interpretation
- •7.1 Information in SEM Images
- •7.2.2 Calculating Atomic Number Contrast
- •Establishing a Robust Light-Optical Analogy
- •Getting It Wrong: Breaking the Light-Optical Analogy of the Everhart–Thornley (Positive Bias) Detector
- •Deconstructing the SEM/E–T Image of Topography
- •SUM Mode (A + B)
- •DIFFERENCE Mode (A−B)
- •References
- •References
- •9: Image Defects
- •9.1 Charging
- •9.1.1 What Is Specimen Charging?
- •9.1.3 Techniques to Control Charging Artifacts (High Vacuum Instruments)
- •Observing Uncoated Specimens
- •Coating an Insulating Specimen for Charge Dissipation
- •Choosing the Coating for Imaging Morphology
- •9.2 Radiation Damage
- •9.3 Contamination
- •References
- •10: High Resolution Imaging
- •10.2 Instrumentation Considerations
- •10.4.1 SE Range Effects Produce Bright Edges (Isolated Edges)
- •10.4.4 Too Much of a Good Thing: The Bright Edge Effect Hinders Locating the True Position of an Edge for Critical Dimension Metrology
- •10.5.1 Beam Energy Strategies
- •Low Beam Energy Strategy
- •High Beam Energy Strategy
- •Making More SE1: Apply a Thin High-δ Metal Coating
- •Making Fewer BSEs, SE2, and SE3 by Eliminating Bulk Scattering From the Substrate
- •10.6 Factors That Hinder Achieving High Resolution
- •10.6.2 Pathological Specimen Behavior
- •Contamination
- •Instabilities
- •References
- •11: Low Beam Energy SEM
- •11.3 Selecting the Beam Energy to Control the Spatial Sampling of Imaging Signals
- •11.3.1 Low Beam Energy for High Lateral Resolution SEM
- •11.3.2 Low Beam Energy for High Depth Resolution SEM
- •11.3.3 Extremely Low Beam Energy Imaging
- •References
- •12.1.1 Stable Electron Source Operation
- •12.1.2 Maintaining Beam Integrity
- •12.1.4 Minimizing Contamination
- •12.3.1 Control of Specimen Charging
- •12.5 VPSEM Image Resolution
- •References
- •13: ImageJ and Fiji
- •13.1 The ImageJ Universe
- •13.2 Fiji
- •13.3 Plugins
- •13.4 Where to Learn More
- •References
- •14: SEM Imaging Checklist
- •14.1.1 Conducting or Semiconducting Specimens
- •14.1.2 Insulating Specimens
- •14.2 Electron Signals Available
- •14.2.1 Beam Electron Range
- •14.2.2 Backscattered Electrons
- •14.2.3 Secondary Electrons
- •14.3 Selecting the Electron Detector
- •14.3.2 Backscattered Electron Detectors
- •14.3.3 “Through-the-Lens” Detectors
- •14.4 Selecting the Beam Energy for SEM Imaging
- •14.4.4 High Resolution SEM Imaging
- •Strategy 1
- •Strategy 2
- •14.5 Selecting the Beam Current
- •14.5.1 High Resolution Imaging
- •14.5.2 Low Contrast Features Require High Beam Current and/or Long Frame Time to Establish Visibility
- •14.6 Image Presentation
- •14.6.1 “Live” Display Adjustments
- •14.6.2 Post-Collection Processing
- •14.7 Image Interpretation
- •14.7.1 Observer’s Point of View
- •14.7.3 Contrast Encoding
- •14.8.1 VPSEM Advantages
- •14.8.2 VPSEM Disadvantages
- •15: SEM Case Studies
- •15.1 Case Study: How High Is That Feature Relative to Another?
- •15.2 Revealing Shallow Surface Relief
- •16.1.2 Minor Artifacts: The Si-Escape Peak
- •16.1.3 Minor Artifacts: Coincidence Peaks
- •16.1.4 Minor Artifacts: Si Absorption Edge and Si Internal Fluorescence Peak
- •16.2 “Best Practices” for Electron-Excited EDS Operation
- •16.2.1 Operation of the EDS System
- •Choosing the EDS Time Constant (Resolution and Throughput)
- •Choosing the Solid Angle of the EDS
- •Selecting a Beam Current for an Acceptable Level of System Dead-Time
- •16.3.1 Detector Geometry
- •16.3.2 Process Time
- •16.3.3 Optimal Working Distance
- •16.3.4 Detector Orientation
- •16.3.5 Count Rate Linearity
- •16.3.6 Energy Calibration Linearity
- •16.3.7 Other Items
- •16.3.8 Setting Up a Quality Control Program
- •Using the QC Tools Within DTSA-II
- •Creating a QC Project
- •Linearity of Output Count Rate with Live-Time Dose
- •Resolution and Peak Position Stability with Count Rate
- •Solid Angle for Low X-ray Flux
- •Maximizing Throughput at Moderate Resolution
- •References
- •17: DTSA-II EDS Software
- •17.1 Getting Started With NIST DTSA-II
- •17.1.1 Motivation
- •17.1.2 Platform
- •17.1.3 Overview
- •17.1.4 Design
- •Simulation
- •Quantification
- •Experiment Design
- •Modeled Detectors (. Fig. 17.1)
- •Window Type (. Fig. 17.2)
- •The Optimal Working Distance (. Figs. 17.3 and 17.4)
- •Elevation Angle
- •Sample-to-Detector Distance
- •Detector Area
- •Crystal Thickness
- •Number of Channels, Energy Scale, and Zero Offset
- •Resolution at Mn Kα (Approximate)
- •Azimuthal Angle
- •Gold Layer, Aluminum Layer, Nickel Layer
- •Dead Layer
- •Zero Strobe Discriminator (. Figs. 17.7 and 17.8)
- •Material Editor Dialog (. Figs. 17.9, 17.10, 17.11, 17.12, 17.13, and 17.14)
- •17.2.1 Introduction
- •17.2.2 Monte Carlo Simulation
- •17.2.4 Optional Tables
- •References
- •18: Qualitative Elemental Analysis by Energy Dispersive X-Ray Spectrometry
- •18.1 Quality Assurance Issues for Qualitative Analysis: EDS Calibration
- •18.2 Principles of Qualitative EDS Analysis
- •Exciting Characteristic X-Rays
- •Fluorescence Yield
- •X-ray Absorption
- •Si Escape Peak
- •Coincidence Peaks
- •18.3 Performing Manual Qualitative Analysis
- •Beam Energy
- •Choosing the EDS Resolution (Detector Time Constant)
- •Obtaining Adequate Counts
- •18.4.1 Employ the Available Software Tools
- •18.4.3 Lower Photon Energy Region
- •18.4.5 Checking Your Work
- •18.5 A Worked Example of Manual Peak Identification
- •References
- •19.1 What Is a k-ratio?
- •19.3 Sets of k-ratios
- •19.5 The Analytical Total
- •19.6 Normalization
- •19.7.1 Oxygen by Assumed Stoichiometry
- •19.7.3 Element by Difference
- •19.8 Ways of Reporting Composition
- •19.8.1 Mass Fraction
- •19.8.2 Atomic Fraction
- •19.8.3 Stoichiometry
- •19.8.4 Oxide Fractions
- •Example Calculations
- •19.9 The Accuracy of Quantitative Electron-Excited X-ray Microanalysis
- •19.9.1 Standards-Based k-ratio Protocol
- •19.9.2 “Standardless Analysis”
- •19.10 Appendix
- •19.10.1 The Need for Matrix Corrections To Achieve Quantitative Analysis
- •19.10.2 The Physical Origin of Matrix Effects
- •19.10.3 ZAF Factors in Microanalysis
- •X-ray Generation With Depth, φ(ρz)
- •X-ray Absorption Effect, A
- •X-ray Fluorescence, F
- •References
- •20.2 Instrumentation Requirements
- •20.2.1 Choosing the EDS Parameters
- •EDS Spectrum Channel Energy Width and Spectrum Energy Span
- •EDS Time Constant (Resolution and Throughput)
- •EDS Calibration
- •EDS Solid Angle
- •20.2.2 Choosing the Beam Energy, E0
- •20.2.3 Measuring the Beam Current
- •20.2.4 Choosing the Beam Current
- •Optimizing Analysis Strategy
- •20.3.4 Ba-Ti Interference in BaTiSi3O9
- •20.4 The Need for an Iterative Qualitative and Quantitative Analysis Strategy
- •20.4.2 Analysis of a Stainless Steel
- •20.5 Is the Specimen Homogeneous?
- •20.6 Beam-Sensitive Specimens
- •20.6.1 Alkali Element Migration
- •20.6.2 Materials Subject to Mass Loss During Electron Bombardment—the Marshall-Hall Method
- •Thin Section Analysis
- •Bulk Biological and Organic Specimens
- •References
- •21: Trace Analysis by SEM/EDS
- •21.1 Limits of Detection for SEM/EDS Microanalysis
- •21.2.1 Estimating CDL from a Trace or Minor Constituent from Measuring a Known Standard
- •21.2.2 Estimating CDL After Determination of a Minor or Trace Constituent with Severe Peak Interference from a Major Constituent
- •21.3 Measurements of Trace Constituents by Electron-Excited Energy Dispersive X-ray Spectrometry
- •The Inevitable Physics of Remote Excitation Within the Specimen: Secondary Fluorescence Beyond the Electron Interaction Volume
- •Simulation of Long-Range Secondary X-ray Fluorescence
- •NIST DTSA II Simulation: Vertical Interface Between Two Regions of Different Composition in a Flat Bulk Target
- •NIST DTSA II Simulation: Cubic Particle Embedded in a Bulk Matrix
- •21.5 Summary
- •References
- •22.1.2 Low Beam Energy Analysis Range
- •22.2 Advantage of Low Beam Energy X-Ray Microanalysis
- •22.2.1 Improved Spatial Resolution
- •22.3 Challenges and Limitations of Low Beam Energy X-Ray Microanalysis
- •22.3.1 Reduced Access to Elements
- •22.3.3 At Low Beam Energy, Almost Everything Is Found To Be Layered
- •Analysis of Surface Contamination
- •References
- •23: Analysis of Specimens with Special Geometry: Irregular Bulk Objects and Particles
- •23.2.1 No Chemical Etching
- •23.3 Consequences of Attempting Analysis of Bulk Materials With Rough Surfaces
- •23.4.1 The Raw Analytical Total
- •23.4.2 The Shape of the EDS Spectrum
- •23.5 Best Practices for Analysis of Rough Bulk Samples
- •23.6 Particle Analysis
- •Particle Sample Preparation: Bulk Substrate
- •The Importance of Beam Placement
- •Overscanning
- •“Particle Mass Effect”
- •“Particle Absorption Effect”
- •The Analytical Total Reveals the Impact of Particle Effects
- •Does Overscanning Help?
- •23.6.6 Peak-to-Background (P/B) Method
- •Specimen Geometry Severely Affects the k-ratio, but Not the P/B
- •Using the P/B Correspondence
- •23.7 Summary
- •References
- •24: Compositional Mapping
- •24.2 X-Ray Spectrum Imaging
- •24.2.1 Utilizing XSI Datacubes
- •24.2.2 Derived Spectra
- •SUM Spectrum
- •MAXIMUM PIXEL Spectrum
- •24.3 Quantitative Compositional Mapping
- •24.4 Strategy for XSI Elemental Mapping Data Collection
- •24.4.1 Choosing the EDS Dead-Time
- •24.4.2 Choosing the Pixel Density
- •24.4.3 Choosing the Pixel Dwell Time
- •“Flash Mapping”
- •High Count Mapping
- •References
- •25.1 Gas Scattering Effects in the VPSEM
- •25.1.1 Why Doesn’t the EDS Collimator Exclude the Remote Skirt X-Rays?
- •25.2 What Can Be Done To Minimize gas Scattering in VPSEM?
- •25.2.2 Favorable Sample Characteristics
- •Particle Analysis
- •25.2.3 Unfavorable Sample Characteristics
- •References
- •26.1 Instrumentation
- •26.1.2 EDS Detector
- •26.1.3 Probe Current Measurement Device
- •Direct Measurement: Using a Faraday Cup and Picoammeter
- •A Faraday Cup
- •Electrically Isolated Stage
- •Indirect Measurement: Using a Calibration Spectrum
- •26.1.4 Conductive Coating
- •26.2 Sample Preparation
- •26.2.1 Standard Materials
- •26.2.2 Peak Reference Materials
- •26.3 Initial Set-Up
- •26.3.1 Calibrating the EDS Detector
- •Selecting a Pulse Process Time Constant
- •Energy Calibration
- •Quality Control
- •Sample Orientation
- •Detector Position
- •Probe Current
- •26.4 Collecting Data
- •26.4.1 Exploratory Spectrum
- •26.4.2 Experiment Optimization
- •26.4.3 Selecting Standards
- •26.4.4 Reference Spectra
- •26.4.5 Collecting Standards
- •26.4.6 Collecting Peak-Fitting References
- •26.5 Data Analysis
- •26.5.2 Quantification
- •26.6 Quality Check
- •Reference
- •27.2 Case Study: Aluminum Wire Failures in Residential Wiring
- •References
- •28: Cathodoluminescence
- •28.1 Origin
- •28.2 Measuring Cathodoluminescence
- •28.3 Applications of CL
- •28.3.1 Geology
- •Carbonado Diamond
- •Ancient Impact Zircons
- •28.3.2 Materials Science
- •Semiconductors
- •Lead-Acid Battery Plate Reactions
- •28.3.3 Organic Compounds
- •References
- •29.1.1 Single Crystals
- •29.1.2 Polycrystalline Materials
- •29.1.3 Conditions for Detecting Electron Channeling Contrast
- •Specimen Preparation
- •Instrument Conditions
- •29.2.1 Origin of EBSD Patterns
- •29.2.2 Cameras for EBSD Pattern Detection
- •29.2.3 EBSD Spatial Resolution
- •29.2.5 Steps in Typical EBSD Measurements
- •Sample Preparation for EBSD
- •Align Sample in the SEM
- •Check for EBSD Patterns
- •Adjust SEM and Select EBSD Map Parameters
- •Run the Automated Map
- •29.2.6 Display of the Acquired Data
- •29.2.7 Other Map Components
- •29.2.10 Application Example
- •Application of EBSD To Understand Meteorite Formation
- •29.2.11 Summary
- •Specimen Considerations
- •EBSD Detector
- •Selection of Candidate Crystallographic Phases
- •Microscope Operating Conditions and Pattern Optimization
- •Selection of EBSD Acquisition Parameters
- •Collect the Orientation Map
- •References
- •30.1 Introduction
- •30.2 Ion–Solid Interactions
- •30.3 Focused Ion Beam Systems
- •30.5 Preparation of Samples for SEM
- •30.5.1 Cross-Section Preparation
- •30.5.2 FIB Sample Preparation for 3D Techniques and Imaging
- •30.6 Summary
- •References
- •31: Ion Beam Microscopy
- •31.1 What Is So Useful About Ions?
- •31.2 Generating Ion Beams
- •31.3 Signal Generation in the HIM
- •31.5 Patterning with Ion Beams
- •31.7 Chemical Microanalysis with Ion Beams
- •References
- •Appendix
- •A Database of Electron–Solid Interactions
- •A Database of Electron–Solid Interactions
- •Introduction
- •Backscattered Electrons
- •Secondary Yields
- •Stopping Powers
- •X-ray Ionization Cross Sections
- •Conclusions
- •References
- •Index
- •Reference List
- •Index
\464 Chapter 26 · Energy Dispersive X-Ray Microanalysis Checklist
ness becoming increasingly critical for measurements with X-rays having energies below 1 keV—e.g., Be, B, C, N, O, F— where the surface roughness should be reduced below 50 nm
26 root mean square. Some samples require very little preparation (e.g., a silicon wafer) and others (anything that isn’t flat) require a lot. You may need to embed the samples and standards in epoxy mounting medium (preferably conductive) and use suitable equipment to grind and polish the samples. Appropriate preparation protocols are so specialized that rather than provide an exhaustive list of possible procedures, the analyst is referred to the rich literature on sample preparation:
55Echlin, P., Handbook of Sample Preparation for Scanning Electron Microscopy and X-ray Microanalysis (Springer, New York, 2009)
55Geels, K., Metallographic and Materialographic Specimen Preparation, Light Microscopy, Image Analysis, and
Hardness Testing (ASTM, West Conshohocken, PA, 2006)
55McCall, J., Metallographic Specimen Preparation: Optical
and Electron Microscopy (Springer, New York, 2012).
55Vander Voort, G., Metallography, Principles and Practice (ASM International, Materials Park, OH, 1999)
(iii)Complex standards:
In many cases, complex standards similar to the unknown sample will produce the most accurate results. However, complex standards often are more difficult to work with and it is often hard to find reliable compositional data. Use of complex standards is an advanced topic and rarely justified unless suitable pure element and simple compound standards are not available.
26.2.2\ Peak Reference Materials
Peak reference spectra serve as examples of the shape of an element’s characteristic peaks. A peak reference can serve as a reference for one or more families. Standards materials can be used as references if there are no interferences for that element. Paradoxically, some materials suitable to serve as peak references are not suitable for use as standards, generally due to instability under the electron beam; for example, BaCl2 provides an excellent peak reference for the Ba M-family, but it is unstable under electron bombardment and thus cannot serve as a standard.
26.2.1\ Standard Materials
Standards are specially prepared materials that serve to provide X-ray data for the elements present in the unknown. You will need a standard for each element in the unknown material. Note that some standards can serve for two or more elements, for example, FeS2.
|
To be useful, a standard must be— |
|
\1.\ |
Suitably sized—Practically speaking, most standards range |
|
|
in size from tens of micrometers to a tens of millimeters |
|
\2.\ |
Polished to a smooth, flat surface with surface texture of |
|
|
less than 100 nm (50 nm for low energy X-rays like oxy- |
|
|
gen) |
|
\3.\ |
Mounted in a manner that facilitates placement on the |
|
|
stage perpendicular to the beam |
|
\4.\ |
Conductive or coated with a conductive material |
|
\5.\ |
There are several different classes of standards, in order |
|
|
of the ease of use: |
|
|
\(i)\ |
Pure element standards: |
|
|
The easiest standards to use are pure elements and |
|
|
this is where a novice should start whenever |
|
|
possible. |
|
\(ii)\ |
Simple compound standards: |
|
|
Some elements are not stable as pure elements—N, |
|
|
O, F, Cl, Br, S—and must be provided as com- |
pounds. The easiest to use are typically stable, stoichiometric compounds like alumina (Al2O3) or calcium fluoride (CaF2). With stable stoichiometric compounds, the true composition of the standard is unambiguous. Ideally, the compound is chosen so that there are no interferences between the element’s characteristic peaks.
26.3\ Initial Set-Up
26.3.1\ Calibrating the EDS Detector
Most EDS detectors allow you to configure two different characteristics of the detector—the pulse process time and the energy calibration. Some detectors provide other more advanced options. You will need to consult the manufacturer’s documentation to determine the optimal setting for these parameters. In general, the goal should be to ensure that the detector is configured the same way day-in/day-out even if it means making small compromises to the ultimate performance.
Selecting a Pulse Process Time Constant
\1.\ Most EDS detectors will allow you to make a trade-off between X-ray throughput and detector resolution. Higher throughput comes at the price of poorer detector resolution. This setting is called different things by various vendors—throughput, pulse processor setting, shaping time, or time-constant.
\2.\ Typically, a pulse processor time constant selected in the middle of the allowed range represents the best trade-off. Despite common belief, the highest resolution setting is rarely the optimal choice as this setting is usually accompanied by severe throughput limitations. Usually, it is better to select a moderate resolution and obtain a moderate throughput.
\3.\ On a modern silicon drift detector (SDD), throughput is typically not limited by the pulse-process time but rather through pulse pile-up (coincidence) events. Selecting a very fast process time won’t actually improve usable throughput.
26.3 · Initial Set-Up
\4.\ Be sure to turn off “adaptive shaping” or other mechanisms that adapt the process time dynamically depending upon X-ray flux. Adaptive shaping changes the shape of the characteristic peaks as the count rate varies due to variations in local composition and makes linear peak fitting less accurate.
Energy Calibration
\1.\ Select one material that you will always use to calibrate your detector. Mount a piece of it near your Faraday cup. Copper is a good choice but there are other materials that have both low energy and higher energy X-ray peaks that can be used for calibration.
\2.\ Select a channel width and channel count that fully covers the range of beam energies that you may use. A width of 10 eV/channel and 2,048 channels is a good choice for a 20-keV beam energy. A width of 10 eV/ channel and 4,096 channels is suitable for higher-energy work. Since EDS spectra comprise relatively small size files and computer storage is inexpensive, consider 5 eV per channel, especially for low photon energy work to provide adequate channels to describe the peak. Whatever choice is made, it is important to consistently use that choice.
\3.\ Each day before you start collecting data, collect and store an initial spectrum from your selected calibration material, for example, Cu. Use this spectrum and your vendor’s software to calibrate the energy axis. Usually this involves adjusting the electronics to ensure that the measured peaks are centered around the correct channels. Most modern detectors automatically and dynamically adjust the zero offset and the calibration is just a matter of the software automatically selecting a gain that produces the desired number of eV/channel. Older detectors may require a manual gain and zero offset adjustment using external potentiometers. Regardless of the mechanism, at 10 eV/channel a 0.1 % mis-calibration will correspond to a single channel error in the position of a peak at 10 keV, so the detector calibration should ideally be maintained to better than 0.1 %. Fortunately, modern detectors are able to hold this precision of calibration for days or weeks.
\4.\ Once the detector is calibrated, set the beam energy and probe current to established nominal values and collect a spectrum for a established live time. Save this spectrum as a demonstration that your detector is performing correctly. DTSA-II provides tools to extract and track performance metrics and then plot the results over time as a control chart.
Quality Control
Sooner or later, you will be asked by a client to demonstrate that your instrument was performing correctly when their data was collected. The easiest way to satisfy this requirement and to impress the client is to keep a long term record and present the data as a control chart. DTSA-II provides functionality which permits you to archive the spectra you
465 |
|
26 |
|
|
|
just used to calibrate your detector as a record of the detectors performance. The program extracts efficiency, calibration and other pieces of instrumental data and records them in a database. This database can then be exported as control charts or tabulations. It is a nice way to make the most of the calibration data you have already spent the time to collect.
Maintaining the Working Distance/
Specimen-to-EDS Distance
Maintaining consistent experimental conditions is critical for achieving rigorous quantitative microanalysis. A critical parameter is the specimen-to-EDS distance, SEDS, since
the solid angle of the EDS varies as 1/S2EDS. The SEM and/or EDS manufacturer(s) will have specified the ideal SEM
working distance (WD) at which the EDS central axis intersects the SEM optic axis. An electron probe microanalyzer uses a fixed-focus optical microscope with a very shallow depth-of-focus to bring the specimen to this ideal WD position (to which the wavelength dispersive spectrometers are also focused) on a consistent basis. While very useful, such an optical microscope is rarely available on an analytical SEM, so that another method must be used to select the working distance properly and consistently. The following procedure assumes the use of a flat polished specimen.
\1. \ Load the specimen so that its Z-height is approximately correct for the ideal working distance specified by the manufacturer. Most SEMs provide a mechanical mounting reference frame to approximately set this initial specimen altitude.
\2.\ Using the manufacturer’s specified value of the ideal SEM working distance for EDS (e.g., 10 mm), set the SEM objective lens strength to focus at this optimal working distance, making use of whatever objective lens meter reading is available to monitor this adjustment.
\3.\ Select a low magnification to begin (e.g., 100×). Despite care in polishing, there are almost always a few fine scale scratches or other irregularities to be found. Locate one, and use the stage Z-motion (i.e., motion along the optic axis of the SEM) to bring this scratch into approximate focus, without adjusting the objective lens strength. Increase the magnification in stages to 5000× and refine the focus with the Z-axis motion, not by changing the objective lens strength. If the SEM stage automation system permits, save this Z-parameter.
\4. \ This procedure is likely to be more reproducible at lower probe currents where the convergence angle is larger and depth-of-focus is smaller.
\5. \ Consistency is critical. Always collect your spectra at this ideal working distance. Before collecting each spectrum ensure that the sample surface is at the optimal working distance by setting the objective lens/working distance and bringing the sample into focus using the vertical stage axis.
